3.2V 30Ah 50Ah Li Ion Prismatic Cell LFP LiFePO4 Prismatic Cell with Screw (Grade A)

Busbars and screws are included for screw terminals. For nickel head pads, no busbars will be provided.

BATTERIES ARE SOLD INDIVIDUALLY. BMS Sold separately.

[product_description]

Manufacturer: Gotion Co., Ltd

SPECIFICATIONS for 30Ah Prismatic Cell:

• Size: 100mm(H) x 140mm(L) x 21mm (W)
• Capacity: 30Ah / 50Ah
• Weight: 750g
• Nominal Discharge Current: 6A (0.2C)
• Max Continuous Discharge Current: 60A (3C)
• Max Charge Current: 30A (1C)
• Nominal Voltage: 3.2V
• Max Charge Voltage: 3.65V
• Discharge cutoff Voltage: 2.5V
• Cycle Life: >3000 at 80% DOD
• Top: Stud Terminals, bus bars and screws included

SPECIFICATIONS for 50Ah Li Ion Prismatic Cell:

• Model: INP27148101A-50Ah
• Size: 101mm(H) x 148mm(L) x 27mm (W)
• Capacity: 50Ah
• Weight: 875
• Max Instantaneous Discharge Current: 250A (5C)
• Max Continuous Discharge Current: 100A (2C)
• Max Continuous Charge Current: 50A (1C)
• Nominal Voltage: 3.65V
• Max Charge Voltage: 4.25V
• Discharge cutoff Voltage: 2.8V
• Cycle Life: >3000 at 80% DOD
• Connection: Solder Pads

Installation

With Screw Terminals: Bus bars can be connected to the screw terminals

With Solder Pads: See video. Use nickel strips to weld onto the terminal pads

[/product_description]
